4 3/4" high in front 7" high in back
Size: 14 1/2" X 17 1/2"
Module or Part# |
Description |
Kit Quantity |
| A | Switch and Automotive Fuse |
1 |
| B | Large 1 Filament Bulb and Socket |
2 |
| C | Small Light Bulb and Socket |
2 |
| D | Single Resistor 100 Ohm |
1 |
| E | Parallel Resistors/ 100, 1K, 10K ohm |
1 |
| F | Cigarette LIghter 12V |
1 |
| G | Series Resistors/ (2) 100 ohm, (2) 68 ohm |
1 |
| H | Parallel Resistors/ (3) 560 ohm |
1 |
| I | Large 2 Filament Bulb and Socket |
2 |
| J | Relay 12 V |
1 |
| K | Buzzer |
1 |
| L | Capacitor 470 mfd |
1 |
| M | Resistor with 2 LEDs |
1 |
| N | Pushbutton Switch |
1 |
| O | Resistor with 1 LED |
1 |
| P | NPN Transistor |
1 |
| Q | Variable Resistor |
1 |
| T | SPST Switch |
1 |
| U | Hazard Switch |
1 |
| V | Large 1 Filament Push-in Light Bulb and Socket |
1 |
| W | Sunload Sensor |
1 |
| X | Diodes |
1 |
| Y | 3 LEDs with Zener Diodes |
1 |
| R12-BPC | 12" Red Banana Plug Patch Cords |
12 |
| B12-BPC | 12" Black Banana Plug Patch Cords |
12 |
Price: $1,095.00
Material: 3/16” Acrylic Plastic mounted in slanted wood stand for desk or tabletop use. Hinged top for storage of modules and leads. Plastic has 135 milled holes for inserting individual modules during training. There are (4) 5 volt DC jacks, (9) Ground jacks, and (2) 12 volt AC jacks for test leads.
Power Supply: 12V DC @ 7A Regulated Supply
5V DC @ 3A Regulated Supply
12V AC @ 1A
Modules Included: All mounted on white acrylic plastic, with silk-screened labeling. Banana plugs on back for inserting and removing from test board.
Power Supply: 12V DC @ 7A Regulated Supply
5V DC @ 3A Regulated Supply
12V AC @ 1A
Modules Included: All mounted on white acrylic plastic, with silk-screened labeling. Banana plugs on back for inserting and removing from test board.
Specifications:
GM Trainer
